In aluminium 6061 with hydroformed tubes to ensure greater sturdiness and complete integration of the battery and motor.
Available in 2 sizes:
- M: between 1,65m and 1,79m
- L: taller than 1,80m
If betwen 2 sizes:
- For steering flexibility choose the smaller size since the bicycle is easier to manoeuvre and to overcome obstacles.
- For comfort and longer distances, choose the larger size.
POWERFUL BROSE DRIVE S MOTOR with 90Nm of torque:
Resistant aluminium crank case
Chain gears allowing for a very silent operation of the motor
Sealed bearings to withstand harsh climate conditions.
Ergonomic, allowing for 4 modes of assistance:
0 - No assistance - The battery is not used.
1 - ECONOMIC: Assistance up to 40%: Save battery to extend your trip, 40% assistance is enough to help you face small slopes.
2 - STANDARD: Assistance up to 80%: Perfect for great control of the bicycle and to climb steeper slopes with reasonable effort, this way you can easily keep up with other mountain bikers.
3 - PLUS: Assistance up to 160%: To climb any slope without difficulties, without getting tired and keeping reasonable battery consumption.
4 - BOOST: Assistance up to 320%: to climb steep slopes with technical difficulty or to always ride fast.
The display presents the following information:
Assistance level and battery;
Speed: instantaneous, average, maximum;
Power provided by the user in Watts;
Distance Travelled: total and trip;
Micro USB socket to charge smartphone or GPS
Assistance button up to 5m/h in pedestrian mode to help push the byke.
POWERFUL 504Wh BATTERY, 100% integrated in the frame, very protected from external elements and with absence of noise and vibrations. Locked with a key, it can easily be removed for charging outside the bicycle, but it can also be charged directly on the bicycle.
RIGID ALUMINIUM FORK
- hollow shaft with 100mm for greater sturdiness with safe “quick release” system for easy removal of the front wheel
SHIMANO NEXUS 8 SPEEDS
Selected to allow ease of use and sturdiness, the transmission has the following characteristics:
- single plate on the front with 38 teeth
- internal shift hub SHIMANO NEXOS with 8 speeds
- handle SHIMANO NEXUS
- chain SHIMANO CN-NX10a E-BIKE
- chain guard HEBIE
The wheels were designed for great safety and sturdiness.
SHIMANO hubs front 100mm and rear NEXUS 8 135mm for SHIMANHO CENTER LOCK disks
Double wall aluminium rims with 36 black anti-corrosion spokes.
Tubeless ready compatible
Equipped with CONTINENTAL 28" tires with 2,2” in width which offer good adherence when curving and braking, traction and PLENTY of comfort in the various types of terrain.
We chose the SHIMANO MT-200 hydraulic brakes with 180mm disks front and rear for greater braking power in steep and prolonged slopes.
Designed for greater control and comfort, we offer a 660mm handlebar with Lem extension ADJUSTABLE in height 0-90 degrees for adjustment in height to the user’s driving position.
ERGON handles with safety lock and driving grips arranged for ergonomics and ease of access.
